Metadata Summary

Problem Reports

No Problem Report Found in the Database

RRS Discovery D381A and D381B Meteorology Quality Report

Wind sensors

Unrealistic wind speeds and the corresponding cycles in wind direction have been flagged as suspect by BODC. (BODC assessment)

Light sensors

All PAR and TIR channels display consistent negative readings during night time. This most likely results from excessive loss of radiation after sunset, which suggests that day-time data recorded during cloud cover should also be treated with caution. Another explanation would be that outdated calibrations added an offset to the data. All negative PAR and TIR data were flagged. (BODC assessment)

There appeared to be instances of shading between the original port/starboard PAR and TIR sensor pairs. This issue was solved by creating a new, unique channel for PAR and TIR respectively, composed of the maximum values per data cycle between each pair of sensors. (BODC assessment)

Data Access Policy

Open Data supplied by Natural Environment Research Council (NERC)

You must always use the following attribution statement to acknowledge the source of the information: "Contains data supplied by Natural Environment Research Council."

Narrative Documents

Gill Instruments Windsonic Anemometer

The Gill Windsonic is a 2-axis ultrasonic wind sensor that monitors wind speed and direction using four transducers. The time taken for an ultrasonic pulse to travel from the North to the South transducers is measured and compared with the time for a pulse to travel from South to North. Travel times between the East and West transducers are similarly compared. The wind speed and direction are calculated from the differences in the times of flight along each axis. This calculation is independent of environmental factors such as temperature.

Specifications

Further details can be found in the manufacturer's specification sheet.

Kipp and Zonen Pyranometer Model CM6B

The CM6B pyranometer is intended for routine global solar radiation measurement research on a level surface. The CM6B features a sixty-four thermocouple junction (series connected) sensing element. The sensing element is coated with a highly stable carbon based non-organic coating, which delivers excellent spectral absorption and long term stability characteristics. The sensing element is housed under two concentric fitting Schott K5 glass domes.

Specifications

RRS Discovery D381A and D381B Meteorology instrumentation

The meteorological suite of sensors was located on the forecastle deck, at approximately 18 m above sea level. The anemometer orientation was 0° on the bow.

Skye Instruments PAR Energy Sensor Model SKE 510

The SKE 510 is suitable for measuring photosynthetically active radiation (PAR) from natural or artificial light sources. The sensor is fully waterproof and guaranteed submersible to 4m depth, and indoor versions are also available.

The instrument uses a blue-enhanced planar diffused silicon detector to measure energy (in W m^-2) over the 400-700 nm waveband. It has a cosine-corrected head and a square spectral response. The sensor can operate over a temperature range of -35 to 70 °C and a humidity range of 0-100% RH.

Specifications

Vaisala PTB110 barometer

An industrial, analog barometer which uses a silicon capacitive sensor (BAROCAP). The sensor produces either frequency or voltage output and is mountable on a (35 mm wide) DIN rail.

Operating ranges (1 hPa = 1 mbar)

General

Accuracy

* Defined as ±2 standard deviation limits of end-point non-linearity, hysteresis error or repeatability error.
** Defined as ±2 standard deviation limits of inaccuracy of the working standard including traceability to NIST.
*** Defined as the root sum of the squares (RSS) of end-point non-linearity, hysteresis error, repeatability error and calibration uncertainty at room temperature when using voltage output.

More detailed information can be found in the manufacturer's data sheet and user's guide.

Vaisala Temperature and Relative Humidity HMP Sensors

A family of sensors and instruments (sensors plus integral displays or loggers) for the measurement of air temperature and relative humidity. All are based on a probe containing a patent (HUMICAP) capacitive thin polymer film capacitanece humidity sensor and a Pt100 platinum resistance thermometer. The probes are available with a wide range of packaging, cabling and interface options all of which have designations of the form HMPnn or HMPnnn such as HMP45 and HMP230. Vaisala sensors are incorporated into weather stations and marketed by Campbell Scientific.

All versions operate at up to 100% humidity. Operating temperature ranges vary between models, allowing users to select the version best suited to their requirements.

Further details can be found in the manufacturer's specification sheets for the HMP 45 series, HMP 70 series and HMP 230 series.

RRS Discovery D381A and D381B Meteorology processing procedures

Originator's Data Processing

The following is adapted from the Discovery 381 cruise report.

Underway surface meteorology and thermosalinograph measurements were recorded by the RVS Surfmet system throughout Discovery cruise 381B.

Processing of the underway data was undertaken in the middle of the cruise to check the quality of the instruments conductivity and temperature measurement, through a check on salinity calibration, and then again at the end of the cruise. Processing entailed running a number of PSTAR routines as detailed below.

• surfmet0 : This script was used to convert the data from RVS format to PSTAR format using datapup. Resultant file was smt381**.raw
• surfmet1 : This ensured absent Surfmet data values were set to -999. The script also calculated TSG salinity using housing temperature, conductivity and a pressure value set to zero. Laboratory calibration of meteorological variables was applied also at this point. The Surfmet system applies the laboratory temperature sensor calibrations before the data reaches the RVS surfmet stream that we read in withsmtexec0.
• surfmet2 : The master Ashtech file and navigation file were merged with smt369** at this point. This allowed accurate heading data to be incorporated into the underway dataset. The data were also averaged to 2 minute values here. This step creates the file smt381**.hdg
• surfmet3 : This routine computed vessel speed and subtracted it from relative winds to obtain true wind speed and direction. Resultant file was smt381**.met

Files delivered to BODC

BODC Data Processing

Data were banked at BODC following standard banking procedures. During reformatting the data were split into two files for the two legs of the cruises D381A and D381B.

The originator's variables were mapped to appropriate BODC parameter codes as follows:

All data expressed at measurement altitude.

Screening

All the reformatted data were visualised using the in-house EDSERPLO software. Suspect data were marked by adding an appropriate quality control flag.

Calibrations

Field Calibrations

No field calibrations were applied to the data at BODC.

Manufacturers Calibrations

PAR/TIR

BODC received Pstar file with manufacturer's calibrations already applied to the PAR and TIR light sensors.

The maximum values between the port-side and starboard-side sensor pairs were extracted into single new PAR and TIR data channels to eliminate the effects of shading. These resulted in the BODC derived parameters DWIRRXMX and CSLRR1XS.

Absolute wind speed and direction

Relative wind speed and direction were corrected for the ship's heading and speed using the gyro heading, ship velocities (calculated at BODC from the main positional channels) and an anemometer orientation of 0° on the bow, thus obtaining the BODC derived absolute wind speed and direction parameters, with codes EWSBSS01 and EWDASS01 respectively.

Air pressure

A manufacturer's calibration was not applied to the barometer because there was no significant offset reported on the certified calibration certificate.

Air temperature and humidity

Manufacturer's calibrations were not applied to the temperature and humidity probe because there were no significant offsets reported on the certified calibration certificate.

Project Information

Ocean Surface Mixing, Ocean Sub-mesoscale Interaction Study (OSMOSIS)

Background

The Ocean Surface Mixing, Ocean Sub-mesoscale Interaction Study (OSMOSIS) consortium was funded to deliver NERC's Ocean Surface Boundary Layer (OSBL) programme. Commencing in 2011, this multiple year study will combine traditional observational techniques, such as moorings and CTDs, with the latest autonomous sampling technologies (including ocean gliders), capable of delivering near real-time scientific measurements through the water column.

The OSMOSIS consortium aims to improve understanding of the OSBL, the interface between the atmosphere and the deeper ocean. This layer of the water column is thought to play a pivotal role in global climate and the productivity of our oceans.

OSMOSIS involves collaborations between scientists at various universities (Reading, Oxford, Bangor, Southampton and East Anglia) together with researchers at the National Oceanography Centre (NOC), Scottish Association for Marine Science (SAMS) and Plymouth Marine Laboratory (PML). In addition, there are a number of project partners linked to the consortium.

Scientific Objectives

• The primary goal of the fieldwork component of OSMOSIS is to obtain a year-long time series of the properties of the OSBL and its controlling 3D physical processes. This is achieved with an array of moorings (two nested clusters of 4 moorings, each centred around a central mooring) and gliders deployed near the Porcupine Abyssal Plain (PAP) observatory. Data obtained from this campaign will help with the understanding of these processes and subsequent development of associated parameterisations.
• OSMOSIS will attempt to create parameterisations for the processes which determine the evolving stratification and potential vorticity budgets of the OSBL.
• The overall legacy of OSMOSIS will be to develop new (physically based and observationally supported) parameterisations of processes that deepen and shoal the OSBL, and to implement and evaluate these parameterisations in a state-of-the-art global coupled climate model, facilitating improved weather and climate predictions.

Fieldwork

Three cruises are directly associated with the OSMOSIS consortium. Preliminary exploratory work in the Clyde Sea (September 2011) to hone techniques and strategies, followed by a mooring deployment and recovery cruise in the vicinity of the Porcupine Abyssal Plain (PAP) observatory (in late Summer 2012 and 2013 respectively). Additional opportunist ship time being factored in to support the ambitious glider operations associated with OSMOSIS.

Instrumentation

Types of instrumentation and measurements associated with the OSMOSIS observational campaign:

• Ocean gliders
• Wave rider buoys
• Towed SeaSoar surveys
• Microshear measurements
• Moored current meters, conductivity-temperature sensors and ADCPs
• Traditional shipboard measurements (including CTD, underway, discrete nutrients, LADCP, ADCP).

Contacts

Data Activity or Cruise Information

Cruise

Complete Cruise Metadata Report is available here

Fixed Station Information

No Fixed Station Information held for the Series

BODC Quality Control Flags

The following single character qualifying flags may be associated with one or more individual parameters with a data cycle:

SeaDataNet Quality Control Flags

The following single character qualifying flags may be associated with one or more individual parameters with a data cycle:
